Outstanding: Permissible system weight up to 180Kg
Shadow Edge Tube 2.0 for an elegant integration of the 625Wh Bosch battery
The E-Bike SUV - Amazing performance both on and off the road
EQUIPMENT
MAIN:
FRAME:
Corratec Life
Permissible system weight up to 180 Kg.
Shadow Edge Tube 2.0 - worldwide most stable and safest corratec E-Bike frame.
Integrated Engine Technology - clean and elegant integrant of the powerful Bosch engine.
Low Entry to get quickly on and off the bike.
FORK:
SR Suntour Mobie25 AIR
Suspension travel: 100 mm
BREAKES:
Magura MT Thirty front
4 Pistons
Size brake disc: 203 mm
Magura MT Thirty rear
Size brake disc: 180 mm
STEM:
Corratec ICR System
HANDLE BAR:
ZZYZX corratec Life Handlebar
SADDLE:
SQ Lab 621 Active
SEAT POST:
ZZYZX SL Alloy Seatpost
Outer diameter: 30.9 mm
DRIVE:
CHAINWHEEL:
SRAM PG1210 Eagle
CASSETTE:
SRAM CS PG1210 11-50T
REAR DERAILLEUR:
SRAM SX Eagle 12S
SHIFT LEVERS:
SRAM SX Eagle Single Click E Trigger
WHEELSET:
RIM:
ZZYZX Cargo 650B front
Rim outer diameter: 27.50 zoll
Type of tires: clincher
ZZYZX Cargo 650B rear
Rim outer diameter: 27.50 zoll
Type of tires: clincher
TIRE:
Continental Race King front
Width: 55 mm
Continental Race King rear
Width: 55 mm
SPECIAL:
CHAINWHEEL RATIO:
1s; 38
CASSETTE RATIO:
12s; 11 13 15 17 19 22 25 28 32 36 42 50
FORK SUSPENSION TRAVEL:
100 mm
SIZE BRAKE DISC
203 mm front 180 mm rear
ENGINE:
BOSCH Performance Line CX
No path too steep, no challenge too great: the Performance Line CX is made for anyone for whom the trail is a second home. eMTB mode will always give you the power you need at precisely the right moment.
Max speed: 25 km/h
Power: 250 watt
Torque: 85 Nm (J)
Max. support of 340% For powerful propulsion, an extremely sporty riding style and fast sprints.
Weight of just approximately 2,9 Kg.
BATTERY:
BOSCH PowerTube 625Wh
What more could you want? The new PowerTube 625 lets you enjoy long and mountainous rides, while still reserving plenty of energy for every adventure. Thanks to a rated capacity of 16.7 Ah and approx. 625 Wh energy content, the lithium-ion battery brings maximum ranges and altitudes within your grasp.
Energy: 625 wh
Voltage: 36V
Weight of just approx. 3,5 Kg
Compatible with DualBattery
LIGHTS:
Herrmans H-Black MR8
REAR CARRIER:
Massload MIK System Direct Mount Carrier
Integrated rear light ensures a clean and smart look.
Direct mount provides more stability and an elegant integration.
