For the P5 we focused entirely on aero performance-within the boxes defined by the UCI, anyway. We applied years of experience in engineering the fastest aero bikes and real-world testing with our pro athletes. The result is a bike that pushes the boundaries in every way possible. We spent hours in CFD, FEA, and ISO testing and the reviews came back from our athletes: BRB.
The P5 has gotten significantly stiffer, but significantly lighter, as well. The frame shapes, handlebar, and fit positions, and design features work together to reduce drag and enhance your efficiency. We wanted a bike that would deliver an aerodynamic advantage over the S5, even in an uphill TT. The P5 is an ideal bike for World Tour racing and UCI-governed TT events, but it's also become a favorite of many of our long-course triathletes. If you don't need the onboard storage of the PX series or have a race with significant elevation gain, the P5 can be the perfect weapon in your race against the clock.
Geometry
48
51
54
56
58
STACK
466MM
486MM
502MM
521MM
539MM
REACH
387MM
403MM
417MM
431MM
437MM
WHEEL SIZE
700C
700C
700C
700C
700C
HEAD TUBE ANGLE
71°
72.5°
72.5°
72.5°
72.5°
FORK OFFSET
52MM
43MM
43MM
43MM
43MM
HEAD TUBE LENGTH
67.5MM
81MM
98MM
117MM
137MM
BOTTOM BRACKET DROP
75MM
75MM
75MM
75MM
75MM
FRONT CENTER
582MM
583MM
602MM
622MM
640MM
WHEELBASE
975MM
976MM
995MM
1015MM
1033MM
STANDOVER HEIGHT
728MM
754MM
769MM
786MM
804MM
Specs
Frame
Cervélo All-Carbon, Tapered P5 Fork
Handlebars
P5 CarbonBasebar/EX10 Riser/Carbon Extensions
Headset
FSA IS2 1 x 1-3/8
Seatpost
Cervélo SP23 Carbon Tri Post
Accessories & Extras
Smartpak 400, Smartpak 100, Aerobottle 500, Rear Hydration Mount
